DCM300MINI
3.2.4 Resistance
Measuring range
400Ω
4kΩ
40kΩ
400kΩ
4ΜΩ
40ΜΩ
There is a little rolling than +50 digits when measuring >
10.00ΜΩ
Overload protection: AC/DC 250V
3.2.5 Circuit Continuity Test
Measuring range
400Ω
Overload protection: AC/DC 250V
Continuity: Built in buzzer sounds when measured
resistance is less than 20Ω and sounds off when measured
resistance is more than 200Ω, between 20Ω to 200Ω the
buzzer maybe sound or off either.
Continuity Indicator: 2kHz Tone Buzzer Response Time of
Buzzer: < 100ms.
3.2.6 Diode Measurement
Measuring range
3.000V
Forward DC current is about 1mA
Open DC voltage is about 3.2V
Overload protection: AC/DC 250V
Resolution
0.1Ω
0.001kΩ
0.01kΩ
0.1kΩ
0.001ΜΩ
0.01ΜΩ
Resolution
0.1Ω
Resolution
0.001V
9
Accuracy
±(1% reading +
5 digits)
±(1% reading +
3 digits)
±(1.5% reading +
5 digits)
Accuracy
±(1% reading +
5 digits)
Accuracy
Display
approximate diode
forward voltage
value
