DCM300MINI
1) Insert red test lead banana plug to
insert black test lead banana plug to
appropriate measuring range.
2) Dial knob switch to
the AC or DC voltage measurement state.
3) Connect the test lead probe with voltage source or both
ends of load in parallel for measurement.
4) Read the voltage value on the LCD.
Note:
1) In the small voltage measuring range, the probe is not
connected with the circuit to be tested, and the meter
may have fluctuating readings, which is normal and
caused by the meter's high sensitivity. When the meter
is connected with the circuit to be tested, you will get
actual measured value.
2) indicates that maximum input voltage is 600V DC or
AC(RMS).4) Read the frequency and Duty ratio on the
LCD.
4.8 Resistance Measurement
Warning
Electric shock hazard.
When measuring circuit impedance, determine that the
power supply is disconnected and the capacitor in the
circuit is completely discharged.
1) Insert black test lead banana plug to
red test lead banana plug to
2) Dial knob switch to
3) Connect the test lead probe to the both ends of resistor
or circuit to be tested for measurement.
4) Read the resistance on the LCD.
Note:
1) When the input end is open, LCD shows "OL" -over
range state.
2) When the resistance to be tested is above 1MΩ, the
display will stabilize after a few seconds, which is normal
for high resistance measuring.
or position, the meter is in
jack
position .
12
EN
jack,
jack, choose
jack, insert
