Scheppach PM1200 Original Bedienungsanleitung Seite 21

m Warning!
Disconnect the machine from the power supply before
assembling or disassembling the stirrer.
Failure to do so may result in accidental starting and
possibly serious injury.
9. Operation
Turning on (Fig. 1)
Press and hold the ON / OFF switch (4), now you can
press the circuit breaker (5) for the ON / OFF switch
to start the handheld mixer. Once the tool is running
properly you can release the circuit breaker (5) for the
ON / OFF switch.
Turning off (Fig. 1)
Release the ON / OFF switch (4). The circuit breaker
for the ON / OFF switch (5) turns off automatically.
Speed controller (Fig. 5)
With the speed controller (6), the power tool's speed
can be gradually adjusted. The type of material to
be mixed determines the speed rate that is required.
Practice will teach you the optimal speed required by
the respective material.
10. Cleaning and Maintenance
ATTENTION!
Unplug the power plug from the electrical outlet
before starting any work on the power tool.
Cleaning
• Keep the air vents of the machine clean in order to
prevent overheating.
• Clean the machine's casing regularly with a soft
cloth, preferably after each use.
• Keep the air vents free from dust and dirt.
• If the dirt cannot be removed easily, use a cloth that
is moistened with soapy water.
ATTENTION!
Do not use solvents such as benzene, alcohol, am-
monia solutions, etc. These solvents may damage
the plastic parts.
Service information
Please note that the following parts of this product are
subject to normal or natural wear and tear, and are
therefore also required as consumables.
Wear parts*: Carbon brush, mixing rod
* Not necessarily included in the scope of delivery!
Spare parts and accessories can be obtained from our
service centre. To do this, scan the QR code on the
cover page.
11. Storage
• The whole machine and all accessories must be
thoroughly cleaned.
• Store devices and accessories out of the reach
of children in a dark and dry place above freezing
point. The optimum storage temperature lies be-
tween 5 and 30 °C. Store the power tool in its orig-
inal packaging.
• Do not wrap the machine into bags or covers made
of nylon or plastic, as dampness may develop.
12. Electrical connection
m The electric motor installed is connected and ready
for operation.
The connection complies with the applicable VDE and
DIN provisions.
The customer's mains power connection as well
as the extension lead used must also comply with
these regulations and the local electricity supplier
regulations.
Damaged electrical connection cables
The insulation on electrical connection cables is often
damaged.
Possible causes:
• Pressure points, where connection cables are
passed through windows or doors.
• Kinks where the connection cable has been improp-
erly fastened or routed.
• Places where the connection cables have been cut
due to being driven over.
• Insulation damage due to being ripped out of the wall
outlet.
• Cracks due to the insulation ageing.
www.scheppach.com GB | 21
