Maintenance procedures
9.5
Opening the unit
WARNING!
To avoid injuries caused by voltages, always disconnect the mains plug and
secure it against being switched on again!
1.
To open the unit, remove both countersunk-head screws on the rear wall.
2.
Turn the unit upside down and put it on the table with the feet facing upwards.
Remove also the lower coutersunk-head screws.
3.
Bend the right and the left housing wall carefully to the outside and separate the
bottom part of the housing from the upper part of the housing by approx. 10 cm.
CAUTION!
The bottom part of the housing can not be fold backwards until the flat plug
connection (PCB) has been taken off.
417101357 Rev. 4-02.2020
32
