Operation

Mounting vessels



Secure vessels on shaker plate

Adaptors for Erlenmeyer flasks, separating funnels and an adaptor with tension rollers for
universal use are available.
▪ To secure vessels on shaker plate, use the optional adaptors (see chapter „Spare
parts and accessories" and chapter „Assembly").
▪ At low shaking speeds, low-profile vessels like petri dishes may be placed directly on
the non-skid rubber plate.
A single flask should be arranged in the middle of the shaker plate.
Several flasks should be distributed equally on the plate.

Shaking mode


Caution:
Risk of breakage and spillage
If the vessels are not attached securely they may fall out and spill the
sample.
Prior to switching the unit on ensure that all vessels are securely
fastened.
Warning:
Risk of poisoning
Open vessels and too high vibration frequencies may result in samples
splashing.
▪ Close all vessels tight especially if sample is dangerous or toxic.
▪ Adjust vibration frequency step by step until you have reached the
required rpm settings.
▪ Wear safety glasses and especially with dangerous and toxic samples
appropriate protective clothing.
Warning:
Risk of injury!
High speeds in combination with high loads and/or a tall assembly
may lead to an unstable device. As result the device may start moving
and slide off the table top.
When working with with high loads and/or a tall assembly, increase
the speed with care and watch for the devices stability. Ensure
the device is installed in such a way as it can not collide with the
surrounding environment or slip off its work surface.
At high loads (load bearing capacity of shaker plate) and high frequency
of shaking, always make reference to load graph as applicable for your
item (refer to „Technical data").
When using shakers inside conditioning cabinets, make reference to
ambient conditions as stipulated in the „Technical data" section.
