Functional description
5. Functional description
5.1 The Programs
The DIGITAL 2000 A has five independent programs. The settings for the different (solder-
ing) tools are saved in these programs and can be changed by the user. By calling up a
program, you can quickly convert the station to another soldering tool or adapt the sta-
tion to different soldering tasks.
Table 1: Program-Tool Assignment
Program
Pr 1
Pr 2
Pr 3
Pr 4
Pr 5
take effect immediately. No temperatures or parameters therefore need to be reset at
the station.
The program is only changed automatically when the tool is changed. The programs 1-4
can be changed manually with the keys (+) and (-). Program 5 can only be called when
a temperature sensor is connected. As long as a temperature sensor is connected the
programs 1-4 cannot be started.
The factory settings apply as long as no setpoints or parameters are entered. The follow-
ing sections describe how to change the settings.
Using the Ersa Tool Selector
The Ersa Tool Selector allows four different soldering and desoldering tools to be used
alternately at the DIGITAL 2000 A. When the Tool Selector is switched, the DIGITAL 2000
A recognizes the given tool and automatically shifts the program. The DIGITAL 2000 A is
therefore ideally suited for use of the Tool Selector.
5.1.1 Program Selection
A program is selected according to the following flow chart (see fig. 2: Program selection
flow chart)
ersa DIGITAL 2000 A
Tool
MICRO TOOL
TECH TOOL/X-TOOL
POWER TOOL
CHIP TOOL
Temperature sensor
3BA00044-00 • 2013-05-23 • Rev. 4
The individual tools are specifically linked to the
respective programs according to Table 1. The
station automatically recognizes when a particular
tool is connected and shifts to the program with
the settings stored for that tool. The settings then
