Technical Data
2. Technical Data
DIG 203 A electronics station
Designation
Supply voltage
Secondary voltage
Output
Control technology
Temperature range
Function display
Cable
Fuse
Design
Soldering iron POWER TOOL
Designation
Voltage
Output
Heat up rating
Heat up time
Weight (without cable)
Cable
Design
Soldering iron TECH TOOL
Designation
Voltage
Output
Heat up rating
Heat up time
Weight (without cable)
Cable
Design
Soldering iron MICRO TOOL
Designation
Voltage
Output
Heat up rating
Heat up time
Weight (without cable)
Cable
Design
Desoldering pincette CHIP TOOL
Designation
Voltage
Output
Heat up rating
Heat up time
Weight (without cable)
Cable
Design
40
Value
230 V~, 50-60 Hz
24 V~
80 W
SENSOTRONIC with digital PID behavior
continuous 50 °C – 450 °C/122 °F – 842 °F
4-character LED display with menu control
2 m PVC with device socket
400 mA, delayed-action
antistatic according to MIL-SPEC/ESA standard
Value
24 V~
105 W/280 °C (536 °F) – 80 W/350 °C (662 °F)
290 W
approx. 40 s (auf 280 °C/536 °F)
approx. 50 g
1.5 m ultra-flexible, heat-resistant, antistatic
antistatic according to MIL-SPEC/ESA standard
Value
24 V~
70 W/280 °C (536 °F) – 60 W/350 °C (662 °F)
130 W
approx. 12 s (auf 280°C)
approx. 50 g
1.5 m ultra-flexible, heat-resistant, antistatic
antistatic according to MIL-SPEC/ESA standard
Value
24 V~
30 W/280 °C (536 °F) – 20 W/350 °C (662 °F)
65 W
approx. 50 s (auf 280°C)
approx. 50 g
1.2 m ultra-flexible, heat-resistant, antistatic
antistatic according to MIL-SPEC/ESA standard
Value
24 V~
2 x 30 W/280 °C (536 °F) – 2 x 20 W/350 °C (662 °F)
130 W
tip-dependent
approx. 75 g
1.2 m ultra-flexible, heat-resistant, antistatic
antistatic according to MIL-SPEC/ESA standard
3BA00044-00 • 2013-05-23 • Rev. 4
ersa DIGITAL 2000 A
