Starting operation
4.2
Switching On for the First Time
Please read through these Operating Instructions completely before commissioning.
Procedure for commissioning:
After the display test has been run through (all display elements briefly light up simulta-
neously), the actual temperature of the soldering tip is displayed. You can now work with
the soldering station.
4.3
Instructions for soldering
You can receive a detailed process description ‚Fine-Pitch Installation' free of charge
upon request from Ersa.
ersa DIGITAL 2000 A
■
Check whether the mains voltage matches the value specified on the
nameplate.
■
Set mains switch to 0.
■
Insert mains lead in the mains connection socket at the back of the
device.
■
Put the dry sponge into the sponge container of the holder.
■
Connect soldering tool to the supply unit and place in holder.
■
Insert mains plug in the socket.
■
Switch on device (set mains switch to I).
■
The soldering station is now ready for operation.
•
The soldering joints must always be clean and grease-free.
•
Soldering times should be as short as possible, but the soldering joint
must be sufficiently and uniformly warmed in order to ensure a good
soldering connection.
•
Before soldering, lightly pierce the soldering tip into the dry sponge
so that it again has a metallic shine. This helps keep the soldering joint
from being contaminated by oxidized solder or burnt flux.
•
Heat the soldering joint by bringing it in equal contact with the pad
and component connection.
•
Add solder wire (e.g. Ersa Sn95,5Ag3,8Cu0,7 solder wire with flux core
according to EN 29454).
•
Repeat soldering procedure.
•
From time to time, pierce the soldering tip into the dry sponge. Dirty
soldering tips lengthen soldering times.
•
Do not clean the soldering tip after the last soldering operation. The
residual solder protects the soldering tip from oxidation.
3BA00044-00 • 2013-05-23 • Rev. 4
43
