WARNING
The noise emission values and vibration
emission value can vary from the specified
values during the actual use of the power
tool, depending on the type and the manner
in which the power tool is used, and in partic-
ular the type of workpiece being processed.
Try to keep the stress as low as possible. For example:
Limit working time. In doing so, all parts of the operating
cycle must be taken into account (such as times in
which the power tool is switched off or times in which it
is switched on, but is not running under a load).
7
Unpacking
WARNING
The product and the packaging material are not
children's toys!
Do not let children play with plastic bags, films or
small parts! There is a danger of choking or suffo-
cating!
• Open the packaging and carefully remove the product.
• Remove the packaging material, as well as the pack-
aging and transport safety devices (if present).
• Check whether the scope of delivery is complete.
• Check the product and accessory parts for transport
damage. Immediately report any damage to the trans-
port company that delivered the Product. Later claims
will not be recognised.
• If possible, keep the packaging until the expiry of the
warranty period.
• Familiarise yourself with the product by means of the
operating manual before using for the first time.
• With accessories as well as wearing parts and re-
placement parts use only original parts. Spare parts
can be obtained from your specialist dealer.
• When ordering please provide our article number as
well as type and year of manufacture for the product.
8
Before commissioning
8.1
Wall mounting of the charger (13)
(Fig. 1)
WARNING
–
Before wall mounting, make sure that there are no
lines in the wall in the area of the drill holes that
could be damaged.
–
Lay the mains cable so that it does not obstruct you
and no one can accidentally pull on it.
–
Children must not play with the product, even if it is
hanging on the wall.
–
Mounting behind doors and their swinging range is
not recommended, as there is a risk of tearing off or
otherwise damaging the product.
WARNING
The product must never be operated on a combustible
surface.
WARNING
Never attach the product to a wet surface.
* = not included in the scope of delivery!
The battery charger has two holes on its back for wall
mounting with two screws*. It can be hung on a wall, tak-
ing into account the safety instructions and the dimen-
sions given (see Fig. 1).
8.2
Fitting the belt clip (11) (fig. 1)
1. During work breaks, the product can be hooked onto
the belt with the integrated belt clip (11).
Note:
Make sure that the product is switched off and secured
against being switched on.
9
Operation
The cordless impact drill with 2-gear transmission has a
25 level torque adjustment +1 screw setting +1 drill set-
ting +1 hammer-drill setting, clockwise/anticlockwise rota-
tion, quick-release chuck and an LED work lamp.
Please refer to the following descriptions for the function
of the controls.
WARNING
Danger of injury!
Remove the battery from the power tool before carrying
out any work on the power tool (e.g. maintenance, tool
change, etc.) and when transporting and storing it.
There is a risk of injury if the on/off switch is operated
unintentionally.
ATTENTION
Make sure that the ambient temperature does not ex-
ceed 50°C and does not fall below -20°C during work.
ATTENTION
The product is part of the 20V gomag series and may
only be operated with batteries of this series. Batteries
may only be charged with battery chargers of this se-
ries. Observe the manufacturer's instructions.
9.1
Inserting/removing the battery (5)
in the battery mount (6) (Fig. 2)
Inserting the battery
1. Put the rotational direction switch (10) in the middle
position (lock).
2. Push the battery (5) into the battery mount (6). The
battery (5) clicks into place audibly.
Removing the battery
1. Press the unlock button (7) of the battery (5) and re-
move it from the battery mount (6).
www.scheppach.com
GB | 23
