• Failures of the electrical system in the event of the
electrical regulations and VDE provisions 0100, DIN
57113 / VDE0113 not being observed.
Note:
The operating manual is part of this product.
It includes important instructions for the safe, proper and
economic operation of the product, for avoiding danger,
for minimising repair costs and downtimes and for in-
creasing the reliability and extending the service life of the
product. In addition to the safety instructions in this oper-
ating manual, you must also observe the regulations ap-
plicable to the operation of the product in your country.
Familiarise yourself with all operating and safety instruc-
tions before using the product. Only operate the product
as described and for the specified areas of application.
Keep the operating manual in a good place and hand
over all documents when passing the product on to third
parties.
2 Product description (fig. 1)
1. Chuck opening
2. Quick-release chuck
3. Torque adjusting ring
3a. Mode selection adjusting ring
4. Gear selector switch
5. Battery
6. Battery mount
7. Release button (battery)
8. LED work lamp
9. On/off switch
10. Rotational direction switch
11. Belt clip
12. Screw
13. Battery charger
14. LED strips (battery charger)
15. Wall bracket
16. Bits
17. Bit holder
18. Metal drill
19. Wood drill
20. Sockets
21. Measuring tape (5m)
22. Countersink
23. Center punch
24. Cutter knife
25. Mine
26. Carpenter's pencil
27. Button for battery charge status indicator
28. Charge status indicator
3 Scope of delivery (Fig. 1)
Item QuantityDesignation
5. 1 x Battery 20V 2Ah (item no. 7909201708)
11. 1 x Belt clip
12. 1 x Screw
13. 1 x Battery charger 20V 2.4 A
(item no. 7909201710)
16. 40 x Bits
17. 1 x Bit holder
18. 14 x Metal drill
19. 5 x Wood drill
20. 8 x Sockets
21. 1 x Measuring tape (5m)
22. 1 x Countersink
23. 1 x Center punch
24. 1 x
25. 1 x
26. 1 x
1 x
1 x
4 Proper use
The product is intended for screwing in and unscrewing
screws, as well as for drilling into wood, metal and plastic
and for hammer-drilling into masonry.
The product may only be used in the intended manner.
Any use beyond this is improper. The user/operator, not
the manufacturer, is responsible for damages or injuries
of any type resulting from this.
An element of the intended use is also the observance of
the safety instructions, as well as the assembly instruc-
tions and operating information in the operating manual.
Persons who operate and maintain the product must be
familiar with the manual and must be informed about po-
tential dangers.
The liability of the manufacturer and resulting damages
are excluded in the event of modifications of the product.
The product may only be operated with original parts and
original accessories from the manufacturer.
The safety, operating and maintenance specifications of
the manufacturer, as well as the dimensions specified in
the technical data, must be observed.
Please note that our products were not designed with the
intention of use for commercial or industrial purposes. We
assume no guarantee if the product is used in commercial
or industrial applications, or for equivalent work.
Explanation of the signal words in
the operating manual
DANGER
Signal word to indicate an imminently haz-
ardous situation which, if not avoided, will re-
sult in death or serious injury.
WARNING
Signal word to indicate a potentially hazard-
ous situation which, if not avoided, could re-
sult in death or serious injury.
CAUTION
Signal word to indicate a potentially hazard-
ous situation which, if not avoided, could re-
sult in minor or moderate injury.
ATTENTION
Signal word to indicate a potentially hazard-
ous situation which, if not avoided, could re-
sult in product or property damage.
www.scheppach.com
Cutter knife
Mine
Carpenter's pencil
Cordless impact drill
Operating manual
GB | 19
