Montageanleitung | Montagehandleiding | Instructions for assembly | Instructions de montage | 130373-0000 | v1 | 2024-02-19
CE mark
Weinor GmbH & Co. KG declares that
the Opal Design II / LED is in compli-
ance with the basic requirements and
relevant provisions of the EN stan-
dards. Opal Design II / LED meets the
requirements of the wind resistance
class indicated in the CE conformity
marks. The requirements shall only
be deemed as having been met once
the manufacturer's instructions have
been adhered to.
Wind resistance class according to EN 13561
With reference to the delegated regulation EU 2019/1188, the test pressures for folding arm
awnings must be carried out without taking the alpha value into consideration.
That is why our awnings are now certified with wind resistance class 1 instead of 2.
The wind stability (nominal wind pressure 40 - 42 N/m²) of the folding arm awnings
remains the same as for the previously valid wind resistance class 2.
That is to say, the maximum recommendation for use up to wind strength 5 on the Beaufort
scale remains. (For more information, also refer to the guideline for technical advice for folding
arm awnings from the IVRSA, Chapter 2.1)
Qualifications
These instructions are addressed to trained fitters and require qualifica-
tion and knowledge of installation techniques:
– Occupational safety at work, operating safety and accident prevention
regulations
– Handling of ladders, scaffolding, tools and machines,
– Transport of long, heavy components and glass panes,
– Estimation of the building structure and fitting the fixing materials,
– Installation, start-up and operation of the product.
• Employ a professional installation company if you do not possess these
qualifications!
Safety instructions and Safety symbols
Warning!
Danger of electric shock!
• Follow the warning instructions for the prevention of electrical shock!
• Electrical fixed installation may only be carried out by electrically skilled
person according to VDE 100!
• Observe the installation instructions for the electrical devices included in
the delivery!
• Separate the electrical connections from the mains during the installation!
• Only connect electrical termination to mains system with all-pole discon-
necting device and with min. 3 mm contact opening width!
• Only connect the construction if indications on product relating to volta-
ge, frequency and output match those of the power source!
Careful! Personal injury can result from improper
installation and operation of the awning unit!
• Follow safety instructions in order to prevent personal injury!
• Observe the instructions for installation and setting from the manufac-
turer of the drive, switch / control!
• Keep packaging, sheeting and small parts away from children (choking
hazard)!
• Do not left the awning on top of the housing! The top of the housing
may break off and the awning will fall (risk of injury, damage to property,
damage to awning)!
• Disconnect current supply when working within the movement range
of the construction (disconnect connector coupling on driver or install
controlled power interruption from the outside)!
• Switch off fuses and automatic control in order to prevent risk of crus-
hing or falling due to uncontrolled movements of the construction!
Nur für das Fachunternehmen
weinor GmbH & Co. KG
Mathias-Brüggen-Straße 110
50829 Cologne
13
Declaration of performance
no. 221125-OD
EN 13561:2004+A1:2008
Opal Design II / LED
Folding arm awning
Installation in outdoor areas
Resistance against wind loads
Wind resistance class 1
|
Alleen voor het vakbedrijf
• Do not lean ladders against the awning or fix them to the awning!
• Ladders must be on a firm base and provide adequate support!
• Only use ladders with adequate load-bearing capacity!
• Use appropriate anti-fall guards to prevent the danger of falling espe-
cially when working at considerable heights!
Mounting brackets:
• Check that the type and number of the mounting brackets supplied are
compliant with the order!
• Check that the information provided in the order about the installation
surface tallies with the actual installation surface on site! Installation is
inadmissible in case of safety-relevant deviations!
Fixing material:
• Use suitable installation and fitting materials (plugs, bolts, resin etc.)
corresponding to onsite conditions and loads!
• Check whether the awning can be installed with the type and number
of brackets recommended by the manufacturer.
• Check whether the awning can be fitted taking the extraction forces
specified by the manufacturer into account.
• When installing, observe the manufacturer's recommendations for the
fixing material used.
Crushing and shearing zones:
• Crushing and shearing zones exist between movable components and
moving awnings parts (projection profile, housing, folding arms, profi-
les) which could catch and draw in clothing or body parts!
• Only activate awnings up to 2.5 m installation height or awnings above
accessible traffic routes if the moving parts are within your line of vision!
Electrical controls, radio controls with latch switches, stand-alone latch
switches, etc. are not permissible in this case!
• The key switch must be fitted in the line of vision of the projection
profile, but far enough removed from the movable parts, at a height
of 1.5 metres (national regulations relating to disabled people must be
observed)!
Partly mounted awnings:
• In awnings which are partly mounted in the factory, secure the spring-
tensioned parts (designated by the manufacturer) against unintentional
opening!
• Caution! Do not remove this locking device until the installation of the
awnings has been completed in order to prevent the high risk of injury
that could result from unintentional opening of spring-tensioned parts!
Test run:
• When ascending the awning for the first time, the working range of the
awning and the area below it must be kept clear!
• A visual inspection of the fixing material and brackets must be perfor-
med after the awning has been extended for the first time!
• When carrying out test runs, never use automatic system control or
switches if the awning is not in the operator's line of vision!
• Use the adjustment set for the motor connection!
Caution!
Product and/or material damage!
• Protect the packaging from moisture (dampened packaging can loosen
during transport)!
• Seal open packaging for further transport!
• The awning must be carried to the place of installation the right way
round so it does not have to be turned round again in a confined space.
• Remove awning from the packaging and secure tightly with hauling ropes!
• Lift the awning horizontally and evenly!
- Tool list → weinor Downloadcenter (DLC)
- Exploded drawing → weinor Downloadcenter (DLC))
|
Only for the specialist retailer
|
Seulement pour l'entreprise spécialisée
