Montageanleitung | Montagehandleiding | Instructions for assembly | Instructions de montage | 130373-0000 | v1 | 2024-02-19
3
Montage der Konsolen auf nicht druckfestem Untergrund oder Dämmfassaden (Dämmverbundsystemen)
de
Montage van de consoles op niet-drukbestendige ondergronden of isolerende gevels (isolatiecomposiet systemen)
nl
Mounting the brackets on non-pressure-resistant surfaces or insulating facades (insulation composite systems)
en
Montage des consoles sur un support non résistant à la pression ou sur des façades isolantes
fr
*
Montage mit Thermax auch ohne Montageplatte möglich
* Installatie met Thermax ook mogelijk zonder montageplaat
* Installation with Thermax also possible without mounting plate
* Montage avec Thermax également possible sans plaque de montage
Verwendung von Montageplatten bei geringer Tragfähigkeit einer Fassade und/oder hohem Gewicht der Markise
de
Gebruik van montageplaten bij geringe draagkracht van een façade en/of hoog gewicht van de zonwering
nl
Use of mounting plates in case of low load-bearing capacity of a façade andor high weight of the awning
en
Utilisation de plaques de montage en cas de faible capacité de charge d'une façade et / ou de poids élevé du store
fr
660x340x15
Nur für das Fachunternehmen
14
M12
M12
14
660x220x15
|
Alleen voor het vakbedrijf
60 Nm
410x160x15
|
Only for the specialist retailer
Stirnseitige Deckenmontage
Plafondmontage voorzijde
Ceiling mounting on the front
Montage frontal au plafond
|
Seulement pour l'entreprise spécialisée
M12
60 Nm
15
