Putting into operation/setting radio reception

6. Putting into operation/setting radio reception

Putting radio reception into operation

The receiver must be selected with a transmitter in SELECT mode to

configure the settings in the receiver. In SELECT mode, there is only

one connection to a selected receiver. Only this receiver can be

moved and configured.

6.1. Selecting a receiver

Pressing the SELECT button for 3 seconds sets the transmitter to

SELECT mode. After SELECT mode has been started, the status LED

begins to flash quickly and the transmitter searches for the receiv-

ers. When the status LED lights up green, this indicates that receiv-

ers have been found and the status LED slowly flashes orange. The

first receiver makes a short confirmation run. If no receivers have

been found, this is indicated by the status LED lighting up red.

Receiver selection with non-programmed transmitter/initial com-

missioning

>1 s

2. Press the SELECT button on the transmitter for 3 seconds. The

transmitter is in SELECT mode.

Receiver selection with programmed transmitter

1. Select the transmitter channel on which the receiver is

programmed.

2. Press the SELECT button on the transmitter for 3 sec-

onds. The transmitter is in SELECT mode.

3 s

Note: The receivers found with this method can now be found using

another non-programmed transmitter within 4 minutes. To do this,

press the SELECT button on the additional transmitter for 3 seconds.

The transmitter is in SELECT mode. All settings can now be config-

ured using both transmitters.

1. Interrupt the voltage supply to the

receivers for > 1 second. The receiv-

ers can be found within the next

4 minutes.

3 s
