Operation on commeo Receive Up/Down
Behaviour of the secondary stations in the operating state – switch
Secondary station
signal
S permanent
S permanent
No signal at S
S
Changing over the secondary station inputs – switch/pushbutton
Button actuation
Button INPUT
>6 seconds
Button INPUT
<1 second
Button INPUT
>3 seconds or auto-
matically after
2 minutes
Function description
The drive moves up to the end position.
The drive moves down to the end position.
or The drive stops.
Function description
Setting the secondary
station input in pushbut-
ton or switch mode.
Changing over the func-
tion between pushbut-
ton and switch.
Setting is exited.
28
LED-display
The LED lights up
blue with this set-
ting.
1x flashes blue =
pushbutton mode
2x flashes blue =
switch mode
1x flashes blue =
pushbutton mode
2x flashes blue =
switch mode
LED lights up blue
after 3 seconds until
the button is
released.
