Operation on commeo Receive Up/Down
Setting the secondary station input in pushbutton or switch mode
The secondary station inputs are designed ex works for connecting
a pushbutton. If a switch is to be used, the function of the second-
ary station inputs must be changed over.
Behaviour of the secondary stations in the operating state – push-
button
Secondary station
signal
S <0.5 seconds
S <0.5 seconds
S or S
<0.5 seconds
S
or S
double-tap within
0.5 seconds
* In the "Blind" receiver application, the receiver does not go into
self-hold mode until >1.5 seconds.
Function description
The drive moves up to the end position.*
The drive moves down to the end position.*
The drive stops.
The drive moves to the set intermediate posi-
tions. The intermediate positions can only be
set using a transmitter.
