How to change temperature between °C and °F
Your Braun ThermoScan is shipped with the Celsius (°C) temperature scale activated . If you wish to switch to Fahrenheit
(°F) and/or back from Fahrenheit to Celsius, proceed as follows:
1 . Make sure the thermometer is turned off .
2 . Press and hold down the Power button . After about 3 seconds the display will show this
sequence: °C / SET / °F / SET .
3 . Release the Power button when the desired temperature scale is shown . There will be a
short beep to confirm the new setting, then the thermometer is turned off automatically .
Care and cleaning
The probe tip is the most delicate part of the thermometer . It must be clean and intact to ensure accurate
readings . If the thermometer is ever accidentally used without a Hygiene cap, clean the probe tip as follows:
Very gently wipe the surface with a cotton swab or soft cloth moistened with alcohol . After the
alcohol has completely dried out, you can put a new Hygiene cap on and take a temperature
measurement .
If the probe tip is damaged, please contact Consumer Relations .
Use a soft, dry cloth to clean the thermometer display and exterior . Do not use abrasive cleaners .
Never submerge this thermometer in water or any other liquid . Store thermometer and Hygiene
caps in a dry location free from dust and contamination and away from direct sunlight .
Additional Hygiene caps (LF 40) are available at most stores carrying Braun ThermoScan .
Replacing the batteries
The thermometer is supplied with two 1 .5 V type AA (LR 06) batteries . For best performance, we recommend alkaline
batteries .
1 . Insert new batteries when the battery symbol appears on the display .
2 . Open the battery compartment . Remove the batteries and replace with new batteries, making
sure the poles are in the right direction .
3 . Snap battery door into place .
Only discard empty batteries . They should not be disposed of in the household waste, but
at appropriate collection sites or at your retailer .
6
Errors and troubleshooting
Error message Situation
No Hygiene cap is attached .
The thermometer probe was not positioned
securely in the ear .
An accurate measurement
was not possible .
Ambient temperature is not within
the allowed operating range
(10 – 40 °C or 50 – 104 °F) .
Temperature taken is not within
typical human temperature range
(34 – 42 .2 °C or 93 .2 – 108 °F) .
HI = too high
LO = too low
System error – self-check display flashes
continuously and will not be followed by
the ready beep and the ready symbol .
If error persists,
If error still persists,
Battery is low, but thermometer will still
operate correctly .
Battery is too low to take correct
temperature measurement .
Product specifications
Displayed temperature range:
Operating ambient temperature range:
Storage temperature range:
Operating relative humidity:
Storage relative humidity:
Display resolution:
Accuracy for displayed temperature range
35 – 42 °C (95 – 107 .6 °F):
Outside this range:
Clinical repeatability:
Battery life:
Battery Type:
Service life:
Accessory:
Reference Body Site:
This thermometer is specified to operate at 1 atmospheric pressure or at altitudes with an atmospheric pressure
up to 1 atmospheric pressure (700 - 1060 hPa) .
Solution
Attach new, clean Hygiene cap .
Take care that the positioning of the probe is correct
and remains stable .
Replace Hygiene cap and reposition .
Press Start button to begin a new measurement .
Allow the thermometer to remain for
30 minutes in a room where
the temperature is between 10 and 40 °C
or 50 and 104 °F .
Make sure the probe tip and lens are clean and a
new, clean Hygiene cap is attached . Make sure the
thermometer is properly inserted . Then, take a new
temperature .
Wait 1 minute until the thermometer turns off
automatically, then turn on again .
. . . reset the thermometer by removing the batteries
and putting them back in .
. . . please contact the Service Centre .
Insert new batteries .
Insert new batteries .
34 – 42 .2 °C (93 .2 – 108 °F)
10 – 40 °C (50 – 104 °F)
-25 – 55 °C (-13 – 131 °F)
10-95% RH (non condensing)
15-95% RH
0 .1 °C or °F
Maximum Laboratory Error
±0 .2 °C (±0 .4 °F)
±0 .3 °C (±0 .5 °F)
±0 .14 °C (±0 .26 °F)
2 years / 350 measurements
2 X 1 .5V type AA (LR 06) batteries
5 years
Hygiene cap, LF40/LF20, single use
Oral Equivalent
English
