Übersicht der Teile und Stückliste der Produkte aus der
7762-Serie
Nummer Bezeichnung
R7762 / 50 - 100 Basisausführung Toilettenbügel
1 Kuppelstück (blau/schwarz/weiß)
2 Abdeckkappe (blau/weiß)
3 Verschlusskappe Ø 32 (blau/schwarz/weiß)
4 Verschlusskappe Ø 25 (blau/schwarz/weiß)
5 Anschlag 2º (blau/schwarz/weiß)
6 Anschlag 0º (blau/schwarz/weiß)
7 Anschlag 4º (blau/schwarz/weiß)
8 Bügel 50 – 100 cm
9 Wandstück
10 Gelenkbuchse
11 Sicherungsbuchse
12 Bolzen, DIN 931, M 10x60
13 Mutter, DIN 934, M10
14 Bolzen, DIN 931, M 8x60
15 Mutter, DIN 934, M8
16 Befestigungssatz (nicht geliefert)
R7764 / 50 – 100 Stützfuß
18 Gelenkstück (blau/schwarz/weiß)
19 Schraubenspindel
20 Schraubenhülse
21 Abdeckkappe (blau/schwarz/weiß)
22 Schraube, DIN 912, M5 x 30
23 Sicherungsmutter, DIN 985, M5
24 Schraube, DIN 912, M5 x 25
25 Mutter, DIN 934, M5
26 Isoliermanschette Ø 5,2 x Ø 6,9
27 Stützfußrohr
28 Stellrohr
29 Rohrverschluss Ø 14
30 Wandscharnier
31 Führungsstück 60 –100 cm
32 Schnellsicherung, Ø 8, PA
33 Gleitlager, Ø 8 x Ø 11 x 7
34 Schnellsicherung, Ø 8, Standardkappe
35 Schnellsicherung, Ø 8, hohe Kappe
R7763 Konsole
36 Stütze
37 Hintere Platte
38 Verschlusskappe der Stütze
39 Klemmstück
40 Mutter, DIN 934, M8
41 Verschlussring, DIN 125, Ø 8,4 x Ø 16
42 Befestigungssatz
R7765 Toilettenrollenhalter
44 Rollenhalter
45 Schnellsicherung, Ø 8
46 Kugelknopf, Ø 25
47 Distanzbuchse Ø 8,2 x Ø 12 x 10
48 Schweißnaht-Abdeckung (blau/schwarz/weiß)
49 Schraube DIN 912, M5 x25
50 Mutter, DIN 934, M5
51 Abdeckkappe (blau/schwarz/weiß)
R7766 Armauflage
53 Armauflage, PUR
54 Leim
Anzahl
1
1
1
1
1
Option
Option
1
1 Satz
1
1
1
1
1
1
1
1
2
4
1
1
1
1
2
1
1
1
1
1
1
2
1
1
1
1
1
2
4
4
1
1
1
1
1
1
1
1
2
1
1
13
General
Toilet support 7762
The 7762 is a foldable toilet support, available in lengths varying between 50 cm and 100 cm and in different models.
The toilet support is intended to function as a universal means of support, also suitable for wet cells.
The standard models come in the following variations:
•
Standard model, without the support leg
•
Standard model with support leg, without the toilet roll holder
•
Standard model with support leg, with toilet roll holder
•
'Comfort' model with armrest and toilet roll holder, available only as a set
•
Same as 'Comfort' plus support leg
Introduction
Invacare is delighted that you have chosen to purchase a quality aid.
Through extensive development and manufacture of bathroom, toilet and shower aids, Invacare has become one of
the foremost companies in this field. The 7762 range of toilet supports meets CE safety standards which form part of
the Medical Devices Directive of 14 June 1993 no. 93/42 EEC.

Warranty

Invacare provides a 2-year manufacturer's warranty on its toilet aids. Normal wear and tear and improper use are not
covered under the terms of this warranty. Invacare is not liable for any personal injury as a result of improper use of
toilet supports.
Safety - general
Ensure that products in the 7762 range are installed in accordance with the attached drawings and instructions.
Toilet supports should preferably be installed by a qualified technician. Always use the means of attachment supplied
by Invacare in the R 6670 assembly kit. The 7762 toilet support can only be fixed to a wall with sufficient load-bearing
capacity (sand lime brick or similar). In all other cases you should use the accompanying support leg (7764 and
7769), or attach the toilet support to the console mounted on the floor (7763). Please contact Invacare if you have
any questions or wish to report any defects.
Installation
Determining the correct height
To maximise ergonomic functioning, the 7762 toilet support must be fitted at the correct height. In order to determine
the correct support height for the user, measure the height from the floor to the knuckle on the user's thumb when the
user is standing in an upright position with stockinged feet. This is the level of the highest point on the toilet support.
Attaching the toilet support to the wall
•
Correctly mark off the holes that need to be drilled on the wall using the wall attachment (use the 2º adjustment
plate for the time being).
•
Drill the holes in the wall and insert the Rawlplugs.
•
Fix the toilet support on the wall, by means of fixations adapted to the nature of
the wall (not supplied).
•
Click the guard into place on the wall attachment pieces.
•
Slide the adjustment plate into place between the wall attachments from
underneath.
Adjusting the height
The toilet support is supplied with a standard 2º adjustment plate. If the support has
been fixed to the wall and it subsequently turns out that the support height differs
somewhat from the required height, the optional 0º and 4º adjustment plates can be
used instead to either lower or raise the support height by 1–2 cm (see accompanying
drawing).
Folding up support rail
The 7762 toilet support rails can be folded into an upright position without any difficulty.
When the support rail is raised from a horizontal position to a vertical position, it will
lock into place automatically when it reaches its most upright position, thus securing the
rail in a vertical position.
To lower the support rail to its horizontal position, lift the rail slightly to release it and
allow it to drop gently into its horizontal position.

Maintenance

The 7762 toilet supports and accessories can be cleaned using water and normal household detergents; do not use a
scouring agent or aggressive solvents.
