Führen Sie nach erfolgter Montage des Bet-
tes eine Überprüfung gemäß Kapitel 6 durch.
Reinigen und desinfizieren Sie das Bett vor
der Erstbenutzung und vor jedem Wiedereinsatz
gemäß Kapitel 5.
Das Bett befindet sich nach erfolgreicher
Durchführung und Beachtung aller Schritte
der Seiten 12 bis 18 im betriebsbereiten
Zustand.
DEMONTAGE
Entfernen Sie den Aufrichter.
Fahren Sie das Bett in die mittele waage-
rechte Position.
Ziehen Sie den Netzstecker aus der Steck-
dose.
Blockieren sie alle vier Laufrollen.
Entfernen Sie die Sicherungsscheiben am
Ende der Bettpfosten.
Nehmen Sie nacheinander alle Seitengitter-
holme ab.
Führen Sie die Kunststoffschieber wieder in
die Führungsschienen ein.
Ziehen Sie die Stecker und die Zugentlastun-
gen aus den Antriebsmotoren des Kopf- und
Fußhauptes.
Heben Sie nacheinander beide Holzumbau-
ten von den Rohrrahmen der Betthäupter ab.
Lösen Sie die Inbusschrauben am Liegeflä-
chenrahmen am Fußende, um den Rohrrahmen
des Fußteils zu entfernen; lösen Sie anschlie-
ßend die Inbusschrauben am Liegeflächenrah-
men am Kopfende, um den Rohrrahmen des
Kopfteils zu entfernen.
Drehen Sie die gelösten Inbusschrauben
wieder in den Liegeflächenrahmen hinein, damit
sie nicht verloren gehen.
G
P
EBRAUCHSANWEISUNG
FLEGEBETT
R
EACHING OPERATIONAL READINESS
After successful assembly, complete an
inspection according to chapter 6.
Clean and disinfect the bed before first time
use and before every further use according to
chapter 5.
After successfully completing and heeding
all steps on page 12 through 18 the bed is
now operationally ready.
DISASSEMBLY
Remove the trapeze pole.
Lower the bed into the middle horizontal
position.
Pull the power plug out of the socket.
Lock all four castors.
Remove the stop washers from the end of
each bedpost.
Remove all side rail beams consecutively.
Insert the plastic slide back into the guide
bar.
Unplug the plugs and strain relief from the
drive motors on the head and foot sections.
Remove the stop plate below the guide bars.
Raise both wooden boards from the tubular
frames of end boards one by one.
Loosen the Allen screws from the reclining
surface frame on the foot section, to remove the
tubular frame from the foot section; next loosen
the Allen screws from the reclining surface
frame on the head section, to remove the tubu-
lar frame from the head section.
Screw the loosened Allen screws back into
the reclining surface frame so they do not get
lost.
