NOTES
This product is equipped with a Röhm drill
u
chuck with an anti-lock function.
If you attempt to open the fully opened
u
chuck further, the anti-lock function will
[ 1 ]
be activated to protect the chuck.
When the anti-lock function is activated,
u
the chuck cannot be closed by turning
[ 1 ]
the chuck ring
2 ] [
A ratcheting sound will be produced when
you attempt to close the chuck.
Deactivating the chuck's
u
function: Turn the chuck ring
clockwise direction by a certain extent.
Then, turn the chuck ring
quickly in a counter-clockwise direction.
Repeat this action if the anti-lock function
is still active. When the anti-lock function is
deactivated, you should be able to close
the chuck without ratcheting sounds.
[ 1 ]
˜ Trial run
NOTE
Always carry out a no-load trial run before
u
starting work and after every accessory
tool replacement. Switch the product off
immediately if the accessory tool is not
running smoothly, if considerable vibration
occurs or if you hear abnormal noises.
Before operating the product, check whether
the accessory tool is correctly positioned, i.e.
centred in the chuck
Screw bits are labelled according to their
dimensions and their shape. If you are
uncertain, always check whether the bit fits
tightly in the screw head without any free
play.
in a clockwise direction.
anti-lock
1 ] [
in a
2 ] [
suddenly and
2 ] [
.
1 ] [
˜ Operation
˜ Gear selection
m ATTENTION! RISK OF PRODUCT
DAMAGE!
Do not operate the gear selector
until the product has come to a
standstill.
Change the gear by sliding the gear
selector forwards or backwards (fig. F).
[ 4 ]
1 gear:
st
Suitable for:
Speed:
Torque:
2 gear:
nd
Suitable for:
Speed:
Torque:
˜ Setting the rotating direction
m ATTENTION! RISK OF PRODUCT
DAMAGE!
Do not operate the rotation direction
switch until the product has come to
[ 5 ]
a standstill.
Change the direction of rotation by pressing
the rotation direction switch
left or right (fig. G).
When the rotation direction switch
the middle position, the on/off switch
locked.
˜ Torque control
This product is equipped with a torque control that
disengages the spindle when a predefined torque
is exceeded.
The torque can be adjusted by turning the
torque sleeve (fig. H).
[ 3 ]
Small screws or soft materials: Select a low
level.
4 ] [
Screwing
Low
High
Drilling
High
Low
towards the
5 ] [
is in
5 ] [
is
6 ] [
