EN
4.3.Deleting the end limit settings: return to default automatic mode
1] Place the motorised product at its half-way position.
2] Press the Up and Down buttons simultaneously until the motorised product
moves up and down.
3] Press the Up, my and Down buttons simultaneously until the motorised
product moves up and down
g The end limit settings are deleted.
NOTICE
The control points, the sensors and the favourite position (my) are still
programmed.
Resume the set-up operation (see Set-up section).
4.4.Restoring the original configuration
NOTICE
• This reset deletes all control points, sensors, end limit settings and resets the drive's favourite position (my).
• Before performing the following steps, disconnect the solar panel and reconnect it after the last step.
1] Place the motorised product at the mid-height position (if possible).
2] Disconnect the drive from the battery for 2 s.
3] Reconnect the drive for 5 to 15 s.
4] Disconnect the drive for 2 s.
5] Reconnect the drive: the motorised product moves for a few seconds. (If the
motorised product is in the upper or lower end limit, it makes a brief up and
down movement).
6] Press the PROG button on the Somfy local control point for≈ 7 s, until the
motorised product moves up and down twice.
g The drive is reset to the original configuration.
Repeat the commissioning procedure (Refer to Commissioning).
5.USE AND MAINTENANCE
NOTICE
This drive does not require any maintenance operations.
5.1.Up and Down buttons
Briefly press the Up or Down button to raise or lower the motorised product fully.
10
1]
3]
1]
3]
ON
5]
ON
©
Copyright 2023 SOMFY ACTIVITES SA. All rights reserved.
RS100 SOLAR io
2]
2]
OFF
2 s
4]
OFF
10 s 2 s
6]
7 s
my
PROG.
