SET-UP INSTRUCTIONS
STEP 6
Remove the 6 screws (26) and washers (25) from the handle support (2).
Connect the hand pulse cable (38) from the left handle (6) to the cable extension (39) from the
handle support (2) and then attach the left handle (6) to the handle support (2) using 3 screws
(26) and 3 washers (25).
Proceed in the same way with the right handle (7).
S6
93
24
7
39
38
39
26
25
38
6
25
26
2
