Product Overview

3 Product Overview
1
1
2
Fig. 1: Adapter without filter
Pos . Designation
1 Magnets
2 Holder
3 Tube clips
4 Retentate tubing
5 Permeate tubing
6 Feed tubing
7 Compression
fittings
8 Adapter
9 Filter clamps
10 Thumb screw
11 Tube interface
block
12 Luer connectors
13 Filter guide
8 Installation Instructions Ambr
3
4
5
6
7
8
Description
Allow the tube interface block to be clipped onto the side of the holder.
Hooks onto the adapter and holds the filter in place during the filtration process.
Attached to filter clamps, allow the hollow fiber filters to be clipped into place when
the filter clamps are vertically orientated.
Connects the retentate port on the adapter to the retentate port on the tube
interface block.
Connects the permeate port on the adapter to the permeate port on the tube
interface block.
Connects the feed port on the adapter to the feed port on the tube interface block.
One at the end of each length of tube, grips around the tubing and screws into the
corresponding port on either the adapter or the tube interface block.
Loads in place of the standard Ambr
module.
Secure the filter in the holder using thumb screws. The clamps offer 2 orientations
(horizontal or vertical) based on the filter type. Tube clips are attached to the filter
clamps to clip the hollow fiber filters in place.
Secures the filter clamps in position in the holder.
Attaches to the holder side with magnets and connects tubing from the adapter to
the filter tubing.
Connect filter tubing to the corresponding port on the tube interface block.
Supports the longer hollow fiber filters and allows the tubing to be clipped on the side.
CF Adapter Kit
®
9
13
10
11
12
10
CF filter to interface with the Ambr
®
Crossflow
®
