1.5. Connecting the IP camera to
the basic electronics 20-0001B-IP,
20-0014B-IP, 20-0016B-IP
1.5.1. LAN connection and power supply for the
camera
The USB to LAN adapter 43-9300 is required
to operate the cameras mentioned in these
instructions in conjunction with one of the three
basic electronics mentioned in section 1.2. At
the start of the following procedure, disconnect
the SIP intercom station from its PoE supply.
Connect the Behnke IP camera to the
RJ45 connector 1 of the USB to LAN adapter.
To do this, first remove the network cable from
the IP camera. If required, extend the LAN cable
from the USB to LAN adapter together with the
network cable and port extender (included with
the Behnke IP camera) (1 m max.). Connect the
4-pin HPI connector
USB port of the SIP intercom station.
Lastly, connect the 2-pin HPI connector
the USB expansion port adapter connector
+/- 12 Volt= of the SIP intercom station.
Please also refer to the mounting example.
Then put the intercom station into operation
(PoE supply).
For connection, see page 27 or in the inst-
ructions supplied with the LAN/USB adapter
(43-9300).
26
2 in the next step to the
3 with
1.5.2. Power supply
Power for the Behnke IP camera is supplied via
the ethernet port (PoE). When operated with
the series 20 IP basic electronics, power for the
camera is supplied via the Behnke USB to LAN
adapter 43-9300.
If the camera is operated independently, all
items described in the technical specifications
of the camera must be observed.
