PROOF W6
Program description

Continuous flow:

DIP switch 4
Enable the continuous flow function to fill the washbasin or a container.
DIP switch 4 ON = Continuous flow function enabled.
DIP switch 4 OFF = Continuous flow function disabled (default setting).
Enable continuous flow
Place your hand approx. 4 cm
in front of the infrared sensor
(below the thermostat knob)
and wait for about 3 s.
30 Wall tap control
Enable continuous flow if
cleaning stop is enabled (DIP
3 = ON)
Place your hand approx. 4 cm
in front of the infrared sensor
(below the thermostat knob)
and wait until water starts
flowing, stops and then starts
flowing again. Continuous
flow is now enabled.
WimTec OCEAN W6
Werkseinstellung:
ON
ON
OFF
OFF
1 2 3 4 5 6
ON
ON
OFF
OFF
1 2 3 4 5 6
ON
ON
OFF
OFF
1 2 3 4 5 6
ON
ON
OFF
OFF
1 2 3 4 5 6
ON
Disable continuous flow
OFF
1 2 3 4 5 6
The function automatically
ends after the time set at
the time control has elapsed.
You can manually disable the
function following the same
procedure used to enable it.
The fitting will resume normal
operation after you leave the
sensor range.
