III. YOUR CHAIR AND ITS PARTS
2
15
18
4
17
5
6
1. Backpost
2. Dual-post, height-adjustable armrest
3. Wheel locks
4. Swing-away footrest
5. Heel loop
6. Aluminum footplate
7. Push handle
8. Tilt-in-space mechanism release lever
9. Rear anti-tip tube
10. 12" Rear wheel
8
11
3
12
13
QUICKIE IRIS
11. Carriage
12. Caster fork
13. Caster tire
14. Tilt indicator
15. Adjustable seat pan
16. Rocker arm
17. Hanger receiver
18. Seat rail
19. Adjustable stroller handle hinge
7
19
1
16
10
9
14
