Functional discription/Error diagnosis
6.5

Offset table

The following table shows the temperature difference between the controller display and
the actual surface temperature of the glass plate.
Temperature
(RA 4500 D)
7.

Error diagnosis

7.1

General errors

If the control station does not operate as expected, check the following items:
If the soldering tip does not become hot after the above items have been checked, the
cause may lie with the hot plate itself or with the temperature sensor. You can check the
continuity in the temperature sensor with an ohmmeter.
26
Note:
The table is only valid in connection with the glass plate and not with the
power grid.
Typ.
heater plate temperature
(IRHP 200)
100 °C 65 °C
150 °C 90 °C
200 °C 120 °C
250 °C 150 °C
300 °C 180 °C
350 °C 210 °C
400 °C 240 °C
450 °C 270 °C
500 °C 295 °C
550 °C 320 °C
600 °C 345 °C
• Mains voltage present? (Correctly connect the mains lead to the
device and socket.)
• Is the fuse defective? The control station does not have its own load
protection, so that the voltage supply is exclusively protected by the
series fuse of the mains connection.
• Is the hot plate correctly connected to the supply unit?
3BA00133 • 2013-06-25 • Rev. 5
Note Temperature
(RA 4500 D)
Recommended
preheating range
Short-time
Typ.
heater plate temperature
(IRHP 200)
212 °F 149 °F
302 °F 194 °F
392 °F 248 °F
482 °F 302 °F
572 °F 356 °F
662 °F 410 °F
752 °F 464 °F
842 °F 518 °F
932 °F 563 °F
1022 °F 608 °F
1112 °F 653 °F
ersa IRHP 200
