Technical Data/Safety information
2.

Technical Data

Control station 4500 D
Operating voltage
Fuse
Output
Control technology
Control accuracy
Temperature sensor
Temperature range
Function display
Power cable
Heating plate
Dimensions
Heated area
Power
Voltage
Heating element
Temperature sensor
3.

Safety information

20
115/230 V~, 50 – 60 Hz
recommended series fuse with 16 A
3000 W (ohm resistive load)
SENSOTRONIC with digital PID behaviour
less than 2 % from temperature accumulated value
thermocouple type J (Fe-CuNi), type K (Ni-CrNi)
continuous, 50° C – 600° C (122° F – 1112° F)
4-character LED display with menu control
1.5 m PVC grounded power cable
Length
Width
Height
260 x 135 mm
800 W
115/230 V~, 50 – 60 Hz
2 ceramic IR-emitter, wave length 2 – 8 µm
thermocouple type K
Attention burn hazard!
The heating element becomes very hot during operation. Flammable or
explosive (battery, electrolytic capacitor) objects, liquids, and gases, must
be removed from the work area of the device. Hot housing elements
should not be brought into contact with the skin or materials that are
sensitive to heat.
Attention burn hazard!
The housing elements are still very hot in the cool-down phase after the
device is switched off
3BA00133 • 2013-06-25 • Rev. 5
300 mm
250 mm
90 mm
ersa IRHP 200
