Symbol Meaning
Tip
Indicates additional information.
, , ... Series of steps
3.
1. 2.
6 Tool list
Hexagon wrench
8 mm
7 Promag, Promass, Prosonic Flow 300, 500,
t-mass, Teqwave M 300
7.1 Removing the transmitter housing, aluminum, cast stainless,
stainless hygienic
WARNING
L
The measuring device is energized!
Risk of fatal injury from electric shock.
‣
Open the measuring device only when the device is de-energized.
CAUTION
L
‣
If spacing is reduced or the dielectric strength of the measuring device cannot be
guaranteed during repair work, perform a test on completion of the work (e.g. high-voltage
test in accordance with the manufacturer' s instructions).
Endress+Hauser
Allen key Torx screwdriver
3 mm, 4 mm
Slotted head
screwdriver
T10, T20
0.5 x 3.5 mm
EA01278D
Long-nose pliers
7
