5. MAP MODIFICATION AND ADAPTATION

• Once the map is created and saved,
click „Room edit" on the main screen on
the right.
1
Automatic map breakdown
• If the first automatic cleaning is done
correctly, the application will automatically
propose a division into individual rooms,
which you can further edit.
The following adjustments can be made:
• A) „Merge" (using this function, you can
join 2 adjacent rooms);
2 • B) „Split" (using this function, you can
divide 1 room in 2 rooms);
• C) „Reset" will delete your map edits;
• D) „Name" (using this function, you can
arbitrarily name rooms);
A) Merging rooms:
• Click on „Merge" and select 2 adjacent
rooms.
3
• Then confirm the selection by clicking on
„Merge". Correct completion is signaled
by a merge success notification.
B) Room segmentation:
• Click on „Split", select the room you
want to split and set the dividing line
using the edge wheels of the line
4
segment.
• Then confirm the selection by clicking
to „Split". Correct completion is signaled
mby a split success notification.
D) Room name
• Click on „Room
to select the room you want to edit the
name of.
5
• Fill in the new name of the room, or
choose from the default names and
confirm each choice by pressing
„Confirm".
• Finally, confirm the changes by clicking
„Save".

Additional settings within map settings

Restricted areas and virtual walls
• On the main screen, click on
6
Edit".
• In this menu you can set A) restricted
zones and B) virtual walls.
7
edit" and then click
8
REMARKS:
• Having finished all necessary settings, save the map.
• 7 forbidden zones of each species and 10 virtual walls can
be inserted into the map.
„Room
ENG
A) Prohibited Zones (Zone)
It is possible to set 2 types of prohibited zones:
area" - the vacuum cleaner
• „Mop forbid
will not mop in the given zone.
• „Mop and sweep" - complete ban on
the movement of the vacuum cleaner
in the given zone.
To add a prohibited zone:
• Click on the appropriate type of prohibited
zone in the menu. The restricted zone can
be moved, rotated, named and resized on
the map with your finger.
• If you want to remove an inserted
prohibited zone, click directly on it with
a finger and then click on „x".
• Finally, save the created zones
by clicking on „Save".
B) Virtual wall (Wall)
• Switch over setting to „Wall".
• After that, click on „Add wall"
• You can insert a virtual wall in the map
move and change its size and direction
with your finger.
• If you want to remove a virtual wall, click
directly on it with a finger and then click
on „x".
• Finally, save the created walls by
clicking „Save".
ENG - 37
