II. EQUIPMENT AND ACCESSORIES
A – vacuum cleaner (Fig. 1, 2, 3)
A1 – ON/OFF (
A2 – power cord winding button
A3 – knob for suction power regulation
A4 – suction vent
A5 – depression for attachment of accessories
A6 – power cord
A7 – rear wheels
A8 – exhaust grid
A9 – output HEPA filter
A10 – exhaust grid aretation
A11 – micro-filter
B – dust container (Fig. 1, 4)
B1 – container lock button
B2 – holder
B3 – cover lock
B4 – cover
B5 – HEPA filter
B6 – suction filter
III. VACUUM CLEANER PREPARATION
Remove all packing material, take out the vacuum cleaner and the accessories.
Remove all possible adhesion foils, stick-on labels or paper from the appliance.
VACUUM CLEANER ASSEMBLY
When assembling the vacuum cleaner, follow the procedure indicated in Fig. 1.
Choose appropriate accessories as required (C1 - C5) (Fig. 5). The telescopic suction tube
C8 can be set to an optimum length to suit the user´s height.
IV. USE OF VACUUM CLEANER
Before use, unwind (by pulling) the power cable A6 from the vacuum cleaner to a required
length and plug the vacuum cleaner to the mains.
CONTROL
A1 button
- vacuum cleaner ON/OFF switch
A2 button - when pressed and held, the unwound part of the power cable rewinds
back inside
Knob A3
- by turning it to the right, you increase the suction power
- by turning it to the left, you reduce the suction power
V. REMOVING THE DUST CONTAINER AND FILTERS
– Maximum suction performance can be achieved when the filters are clean and the
dustbag is empty.
– Every time you empty the dust container, we recommend that you also clean the filters.
– When you are vacuuming very fine dust, the filter pores might get clogged. This
reduces the air flow and the suction performance deteriorates. In such a case, the
filters need to be cleaned even though the container is not full yet.
) button
B7 – separator
B8 – bottom lock button
B9 – bottom flap
B10 – seal 1
B11 – seal 2
B12 – seal 3
B13 – input part
C – accessories (Fig. 1)
C1 – floor nozzle
C2 – parquet nozzle
C3 – upholstery nozzle
C4 – brush
C5 – crevice nozzle
C6 – suction hose
C7 – suction hose locking
C8 – telescopic suction tube
C9 – telescopic suction tube locking
C10 – mechanical suction power regulator
Caution
