English
Only store the unit at ambi-
n
ent temperatures above 0°C
[32°F].
Do not operate the unit
n
without an air filter.
Do not spray aerosols in the
n
vicinity of this appliance
while it is in operation.

2.2 Intended use

The Integration Kit is a cabinet installation
for iCombi Pro the unit size 6-2/3 and is
only intended for use in large and com-
mercial kitchens.
Ensure that the room is adequately ventil-
ated.
Always observe the manual for the unit
and the UltraVent 6-2/3 hood.
3

Product description

3.1 Product overview

The Integration Kit and the UltraVent / Ul-
traVent Plus have the following item num-
bers:
Integration Kit
UltraVent 6-2/3
120V
UltraVent Plus 6-2/3
120V
UltraVent 6-2/3
230V
UltraVent Plus 6-2/3
230V
Scope of delivery [
Position
1
2
12 / 108
Article number
60.74.285
60.74.408
60.74.063
60.74.405
Figure 01]
Description
Right side panel
Left side panel
80.51.597_iCombiPro-iCombiClassic_IntegrationKit_IM_EU-west
Position
3
4
5
6
7
8

3.2 Technical data

Specification
Voltage
Connected load
Exhaust volumes
Noise emission
Specification
Voltage
Connected load
Exhaust volumes
Noise emission
3 | Product description
Description
Perforated plate at
bottom with filter
fastening
Stand for unit mount-
ing in the installation
cabinet
UltraVent body for
installation solution
Superstructure with
impact filter
Cover plate right
hinged
Cover plate left
hinged
Value
1 NAC 230V / 2 AC
200V
170 W
280 - 560 m³/std.
< 60 dBA
Value
1 NAC 120V
170 W
280 - 560 m³/std.
< 60 dBA
