Introduction
Manufacturer:
Scheppach GmbH
Günzburger Straße 69
D-89335 Ichenhausen
Dear Customer
We hope your new product brings you much enjoyment
and success.
Note:
In accordance with the applicable product liability laws,
the manufacturer of this product assumes no liability for
damage to the product or caused by the product arising
from:
• Improper handling
• Non-compliance with the operating manual
• Repairs carried out by third parties, unauthorised
specialists
• Installing and replacing non-original spare parts.
• Improper use.
Note:
Read the whole text of the operating manual before as-
sembly and commissioning.
This operating manual should help you to familiarise
yourself with your product and to use it for its intended
purpose.
The operating manual includes important instructions for
the safe, proper and economic operation of the product,
for avoiding danger, for minimising repair costs and
downtimes and for increasing the reliability and extend-
ing the service life of the product.
In addition to the safety instructions in this operating
manual, you must also observe the regulations applica-
ble to the operation of the product in your country.
Keep the operating manual package with the power tool
at all times and store it in a plastic cover to protect it
from dirt and moisture. They must be read and carefully
observed by all operating personnel before starting the
work.
The product may only be used by personnel who have
been trained to use it and who have been instructed with
respect to the associated hazards.
In addition to the safety instructions in this operating
manual and the separate regulations of your country, the
generally recognised technical rules relating to the oper-
ation of such products must also be observed.
We accept no liability for accidents or damage that occur
due to a failure to observe this manual and the safety in-
structions.
2
Description of the product
1.
Transport handle
2.
Feed hopper
3.
Fuel filler cap
4.
Fuel tank
28 | GB
5.
Engine
6.
Air filter cover
6a.
Cover wing screw
6b.
Air filter wing screw
6c.
Air filter
7.
Base frame
8.
Catch basket safety switch
9.
Oil drain hose
10.
Catch basket
11.
Wheels
12.
Shredding unit
13.
Cover
14.
Loading funnel safety switch
15.
Engine connection cable
16.
Oil filler cap with oil dipstick
17.
Fuel filter insert
18.
On/off switch
19.
Choke lever
20.
Fuel valve
21.
Throttle
22.
Pull starter
23.
Cutter disc
24.
Blade screws
25.
Blade
26.
Spark plug connector
27.
Spark plug
3
Scope of delivery
Item Quantity Designation
1.
1 x
2.
1 x
7.
1 x
10.
1 x
11.
2 x
12.
1 x
A.
1 x
B.
4 x
C.
2 x
D.
4 x
E.
4 x
F.
4 x
G.
4 x
H.
1 x
I.
3 x
J.
7 x
K.
7 x
L.
4 x
M.
1 x
1 x
1 x
4
Proper use
The product is suitable for private use in private gardens
and allotments. A product for private gardens and allot-
ments refers to a device with an annual operating time
generally not exceeding 50 hours, during which time the
device is primarily used to shred organic household and
garden waste. Public facilities, sporting halls, and agri-
cultural/forestry applications are excluded.
www.scheppach.com
Transport handle
Feed hopper
Base frame
Catch basket
Wheels
Shredding unit
Wheel axle
M16 washers
Split pin
Screws M8x35mm
M8 spring washers
Washer M8
M8 locknuts
Feed funnel rubber seal
Screws M6x16mm
M6 spring washers
Washer M6
Screws M6x20mm
Spark plug wrench
Operating manual
Engine operating manual (English)
