Teileliste
Nr.
Anz.
Bezeichnung (ENG)
1
1
Main Frame
2
1
Pedal Arm (L)
3
1
Pedal Arm (R)
4
1
Lower Handle Bar (L)
5
1
Lower Handle Bar (R)
6
2
Bushing Housing, Pedal Arm
7
1
Connecting Arm (L)
8
1
Connecting Arm (R)
9
2
Cross Bar
10
1
Console Mast
11
1
Idler Wheel Assembly
12
1
Crank Axle
13
1
Swing Arm (L)
14
1
Swing Arm (R)
15
2
Rail Tube
16
1
Rail Strap
17
2
Blacking Arbor for Pedal
18
2
Axle for Slide Wheel
19
3
Rod End Sleeve
20
2
6005_Bearing
21
6
6203_Bearing
22
8
6003_Bearing
23
2
Rod End Bearing
Ø31 × Ø25.5 × Ø19 × 16+3T_
24
4
Bushing
25
1
350m/m_Steel Cable
26
1
Drive Belt
27
1
Ø330_Drive Pulley
28
1
Flywheel
29
1
Magnet
Nr.
Anz.
Bezeichnung (ENG)
30
2
25 × 7 × 7m/m_Woodruff Key
31
1
Console Assembly
32
1
1100m/m_Computer Cable
33
1
600m/m_DC Power Cable
34
1
Gear Motor
35
1
250m/m_Sensor W/Cable
36
1
Sensor Rack
850m/m_Handpulse W/Cable
37
2
Assembly
37~4
4
Ø3 × 20m/m_Tapping Screw
38
1
Power Adaptor
39
2
Slide Wheel , Urethane
40~1
2
3/8" × 2"_Flat Head Socket Bolt
40~2
2
Rubber Foot
41
1
Console Mast Cover
42
1
Side Case(L)
43
1
Side Case(R)
44
2
Round Disk
45
2
Round Disk Cover
46
2
Cover Swing Arm Axle
47
1
Pedal Arm Cover (L)
48
1
Pedal Arm Cover (R)
50
1
Pedal (L)
51
1
Pedal (R)
52
2
Slide Wheel Cover
53
4
Button Head Plug
54
1
Front Handle Bar Cover (L)
55
1
Rear Handle Bar Cover (L)
56
1
Front Handle Bar Cover (R)
57
1
Rear Handle Bar Cover (R)
