Teileliste; Spezifikation - Taurus Studio Preacher Curl Montageanleitung

7.2

Teileliste

Nr. Bezeichnung (ENG)
1 Arm support frame
2 Support frame
3 Seat pad frame
6 Junction plate
7 Adjusting handlebar
8 Fixed axle
9 Torsion spring
10 Limiting screw
11 Semi-sliding sleeve
12 Pipe plug
13 Left hook jacket
14 Middle hook jacket
15 Right hook jacket
16 Left extend jacket
17 Middle extend jacket
18 Right extend jacket
19 Lower protecting jacket
20 Upper protecting jacket
21 Rubber mat
22 Split washer
23 Small countersunk head rivet nut
24 Cross head modified truss head screw
25 Hexagon socket button head screw
26 Hex socket head cap screw
27 Nylon insert lock nut
28 Hex socket head cap screw
29 Plain washer
30 Plain washer

Spezifikation

d=6
M8*18
M5*12
M8*30
M8*75
M12
M12*80
Φ16*Φ8.4*1.6
Φ24*Φ13*2.5
Anz.
1
1
1
1
1
1
1
1
2
2
4
4
4
2
2
2
2
2
3
2
2
32
4
2
4
4
10
8
19
