Intended purpose
The bench drill is designed for drilling in
metal, wood and plastic. Straight shank
drills with a drilling diameter from 1 mm to
13 mm can be used.
The device is intended to be used by do-it-
yourselfers. It was not designed for heavy
commercial use. Commercial use will inva-
lidate the guarantee.
The tool is not to be used by persons.
under the age of 16. Children over the
age of 16 may use the tool except under
supervision.
The manufacturer is not liable for damage
caused by an improper use or incorrect
operation of this device.
General description
An illustration of the most im-
portant functional components
can be found on the front and
the back fold-out pages.
Extent of the delivery
Carefully unpack the appliance and check
that it is complete. Dispose of the pa
ckaging material correctly.
- Baseplate
- Drilling bench
- Column tube
- Motor unit
- 3 drill lifting arms
- Safety device
- Drill chuck
- Drill spindle taper
- Mounting accessories (2x hex key,
1x drift key)
- 3x assembly screws
- Instruction Manual
Description of functions
Please refer to the descriptions below for
information about the operating devices.
Overview
1 Gear cover
2 Motor unit
3 Column tube
4 Tommy screw
5 3 assembly screws
6 Baseplate
7 Retaining screw for drilling
bench
8 Drilling bench
9 Angle scale
10 Motor unit clamping screw
11 Laser controller
12 Drill chuck
13 Drill lifting arm
14 Safety device
14a Screw + spacer washer
15 Drill spindle taper
16 Hand spindle guide
17 Display
18 Off switch
19 On switch
20 Laser switch
21 Work light switch
22 Depth stop locking screw
23 Depth stop with scale
24 Mounting accessories
24a Drift key
24b Hex key, 10 mm
24c Hex key, 4 mm
25 Handwheel
26 Clamping screw
27 Swivel joint
28 Circlip
29 Grub screw
30 Drive wheel
31 V-belt
