Instructions for installation and use
7. TECHNICAL DATA
7.1. OPERATING ELEMENT
Connection:
Power consumption:
Ambient conditions:
Housing:
Mounting:
Dimensions USB-dock:
7.2. LED POWER ELEMENT
Supply:
Power consumption:
Ambient conditions:
Housing:
Mounting:
WORLD OF WELLNESS
4-pin with supply and communication lines (3 m)
5 V= / < 100 mA normal operation (< 0,5 W)
0 °C – 130 °C, max. 99 % hum idity, noncondensing!
Flush-mounted box; board; optical fibre for display;
wooden front with temperature-resistant foil. Board
over M2.5 bolt on wooden front; rear with flush-
mounted box.
Fasten to the sauna wall with the screws supplied.
L x B x T: 30 x 92 x 9.5 mm
3-polig 230 V +/- 6 %; 50Hz; with protective con-
ductor (PE)
Depending on chroma and brightness max. 50W.
0 - 50 °C, max. 95 % rel. h. non-co ndensing
Plastic housing with cover
L x B x T = 243 x 214,5 x 70 mm
Fasten housing with screws to the sauna cabin.
p. 19/20
EN
