Installation instructions, only for experts
4. CONNECTION OF SEVERAL sound&light CO-
LOURED LAMPS
Up to 4 sound&light coloured lamps can be controlled via an operating element.
To allow this, the power elements are connected to each other via a BUS line
(RJ12 or RJ11 cable) and controlled via the LED coloured light operating ele-
ment. The LED coloured lamps connected to an operating element can not be
individually controlled but only together.
There must be a power element defined to which the operating element is con-
nected and from which the music data (MP3 or AUX) are given. This is done via
a jumper located on the power element board:
Jumper closed (delivery status)
Power element MASTER
WORLD OF WELLNESS
Jumper open
Power element SLAVE
