Weidmuller UTC/R Bedienungsanleitung Seite 18

1
Mann Series
9 10 11 12 13 14 15 16
9
10
18
Thermocouple Input +
Thermocouple Input –
7
8
2 3 4 5 6 7 8
MICROMANN
AL1 OP AL2
ENT
16
14
11
15
12
13
Power supply
GeneralconnectiondiagramforUTC/R
General connection diagram for UTC/R
Input
Link to enable full setup
(not recommended for
normal operation)
White dot
CJC board fitting
(to terminals 2, 3, 4, & 5)
Alarm channel two
Normally open contact
Common contact
Normally closed contact
Alarm channel one
Normally open contact
Common contact
Normally closed contact
Live (+)
Neutral (–)
