PHA...-F200*-R3*
Inbetriebnahme
Ausgangsposition
Abbildung 6.5
Wenn Sie einen Relativhub von -40 mm eingeben, wandert die Sollposition beim
Einlagern nahe an den Rand des Fangbereichs. Am Rand des Fangbereichs kann
das Loch während des Positionierens schnell außerhalb des Fangbereichs
geraten.
Relativhub RP -40 mm
Abbildung 6.6
Um das zu detektierende Loch jeweils der Mitte des Fangbereichs zu nähern,
verschieben Sie die Nullposition um -20 mm.
Vision Configurator
F a n g
b e r e i
c h
L o c h
Zero position
Relative position
F a n g
Vision Configurator
b e r e i
c h
L o c h
R P
Zero position
Relative position
Horizontal
0
mm
Vertictal
Horizontal
0
mm
Vertictal
Horizontal
0
mm
Vertictal
Horizontal
0
mm
Vertictal
0
mm
0
mm
0
mm
-40
mm
23
