Exploded View - Thermalright AXP-100RH Bedienungsanleitung

AXP-100RH

Exploded View

Important! Before proceeding with installation, please check for the most
up-to-date instructions at www.thermalright.com
Heatsink Body
Anchoring Mount
1
Intel 775/1150/1151/1155/1156/1366
M3 L6 Screw
Screw Nut
Intel Washer (small)
M3 L10 Screw
M3 L17 Screw
TY-100R Fan
Mylar
Metal Back Plate
