AM4/AM2/AM2+/AM3/AM3+/FM1/FM2/FM2+
AXP-100RH
Exploded View
Important! Before proceeding with installation, please check for the most
up-to-date instructions at www.thermalright.com
M3 L17 Screw
TY-100R Fan
Heatsink Body
M3 L6 Screw
Anchoring Mount
Mounting Plate
Screw Nut
AMD Washer (big)
Mylar
Metal Back Plate
M3 L10 Screw
Back Plate Cap
