Thermalright AXP-100RH Bedienungsanleitung Seite 13

Component
1
5
9
14
1
Heatsink Body ×1
4
Mylar ×1
7
Screw Nut ×4
10
M3 L6 Screw ×7
13
Back Plate Cap ×1
16
M3 L4
Screw ×5
The Ultimate Cooling Solutions!
2
6
10 11
15
2
Enhanced Fan Mount ×1
5
Mounting Plate ×1
LGA2011 Type B
8
Screw Pillars x4
11
Intel Washer (small) ×4
14
Chill Factor III ×1
17
M3 L17 Screw ×5
3
7
12
16 17
3
Metal Back Plate ×1
6
Anchoring Mount ×1
9
M3 L10 Screw ×5
12
AMD Washer (big) ×4
15
TY-100R Fan×1
18
M3 L28 Screw ×5
