Abb. 17: Beispiel Mapping einer EL3162 m Standard-Format (8 Byte IN / 0 Byte OUT)
Name
AI Standard Channel 1.BitArray
Status_Underrange
Status_Overrande
Status_Limit_1[0]
Status_Limit_1[0]
Status_Limit_1[0]
Status_Limit_1[0]
Status_Error
Status_Sync error
Status_TxPDO State
Status_TxPDO Toggle
AI Standard Channel 1.Value
AI Standard Channel 2.BitArray
Status_Underrange
Status_Overrande
Status_Limit_1[0]
Status_Limit_1[0]
Status_Limit_1[0]
Status_Limit_1[0]
Status_Error
Status_Sync error
Status_TxPDO State
Status_TxPDO Toggle
AI Standard Channel 2.Value
EK9320
Size (Variable)
BIT (BOOL)
BIT (BOOL)
BIT (BOOL)
BIT (BOOL)
BIT (BOOL)
BIT (BOOL)
BIT (BOOL)
BIT (BOOL)
BIT (BOOL)
BIT (BOOL)
16 BIT (INT)
BIT (BOOL)
BIT (BOOL)
BIT (BOOL)
BIT (BOOL)
BIT (BOOL)
BIT (BOOL)
BIT (BOOL)
BIT (BOOL)
BIT (BOOL)
BIT (BOOL)
16 BIT (INT)
Version: 1.0.0
Konfiguration
Bit offset
0.0
0.1
0.2
0.3
0.4
0.5
0.6
1.5
1.6
1.7
2.0..3.7
4.0
4.1
4.2
4.3
4.4
4.5
4.6
5.5
5.6
5.7
6.0..7.7
