B.3. About the controller
Logic 3 pool controller facilitates efficient use and function control of your
®
The BADU
solar or heating system with your swimming pool. The device is impressive most of all
for its functionality and simple, almost self-explanatory operation. For each step in the
input process the individual entry keys are assigned to appropriate functions and ex-
plained. The controller menu contains headwords for the measured values and settings
as well as help texts or clearly-structured graphics.
The BADU
®
Logic 3 can be used as a solar controller for the various system variants
illustrated and explained under "B.6. Hydraulic variants" on page 7.
Important characteristics of the BADU
-
Depiction of graphics and texts in an illuminated display
-
Simple viewing of the current measurement values
-
Analysis and monitoring of the system by means of statistical graphics, etc.
-
Extensive menu settings with explanations
-
Menu block activation to prevent unintentional setting changes
-
Resetting to factory settings
B.4. Scope of supply
®
BADU
Logic 3 pool controller
-
3 pcs. 3.5 x 35 mm screws and 3 pcs. 6 mm plugs for wall installation
-
6 strain relief clips with 12 screws, replacement fuse 1x T 4 A/250 V
-
BADU
®
Logic 3 installation and operating instructions
Optionally contained depending on design/order:
-
2-3 PT1000 temperature sensors and immersion sleeves
Additionally available:
-
PT1000 temperatur sensors, immersion sleeves, overvoltage protection
-
A wide range of additional functions via additional circuit boards
B.5. Disposal and pollutants
The unit conforms to the European RoHS directive 2011/65/EU for the restriction of the
use of certain hazardous substances in electronic equipment.
The unit must not under any circumstances be disposed of with ordinary
household refuse. Dispose of the unit only at appropriate collection points.
Caution
6
Description of controller
®
Logic 3:
