E.2. Commissioning help

display. Pressing the "esc" key takes you back to the previous value so you can look at
the selected setting again or adjust it if desired. Pressing the "esc" key more than once
takes you back step by step to the selection mode, thus cancelling the commissioning
help. Finally, the menu "4.2. Manual" on page 18 should be used to test the switch
outputs with the consumers connected and to check the sensor values for plausibility.
Then the automatic mode can be switched on.
Observe the explanations for the individual parameters on the following
pages and check whether further settings are necessary for your applica-
tion.
Caution

E.3. Free commissioning

If you decide not to use the commissioning help, you should make the necessary set-
tings in the following sequence:
- Menu 10. Language
- Menu 7.2. Time and date
- Menu 7.1. Program selection
- Menu 5. Settings, all values
- Menu 6. Protective functions, if necessary
- Menu 7. Special functions, if necessary
Finally, the menu "4.2. Manual" on page 18 should be used to test the switch out-
puts with the consumers connected and to check the sensor values for plausibility.
Then the automatic mode can be switched on.
Observe the explanations for the individual parameters on the following
pages and check whether further settings are necessary for your
application.
Caution
Commission
The first time the controller is turned on and
after the language and time are set, a query
appears as to whether you want to param-
etrise the controller using the commissioning
help or not. The commissioning help can also
be terminated or called up again at any time in
the special functions menu. The commission-
ing help guides you through the necessary ba-
sic settings in the correct order, and provides
brief descriptions of each parameter in the
13
