E.4. Menu sequence and menu structure

1. Measurements

2. Statistics

3. Display mode
4. Operating mode
5. Settings
6. Protective functions
7. Special functions
8. Menu lock
9. Service values
10. Language
14
Operation
The graphics or overview mode appears
when no key has been pressed for 2 min-
utes or when the main menu is exited by
pressing the "esc" key.
Pressing a key in the graphics or overview
mode will lead directly to the main menu.
Here the following menues are available:
Current temperature values with explana-
tions
Function control of the system with operat-
ing hours etc.
Select graphics mode or overview mode
Automatic mode, manual mode or switch
unit off
Set parameters needed for normal opera-
tion
Solar and frost protection, anti-seizing
protection etc.
Program selection, sensor calibration,
clock, additional sensor etc.
Against unintentional setting changes at
critical points
For diagnosis in the event of an error
Language selection
