B.1. Specifications
Electrical specifications:
Mains voltage
Mains frequency
Power consumption
Internal fuse
Protection category
Protection class
Overvoltage category
Degree of pollution category
mechanical relay 4 A maximum AC3
PT1000 sensor input measuring range -40 °C
to 300 °C
Permissible cable length of sensors and appliances:
Collector and outdoor sensor
Other PT1000 sensors
Electronic relay
Mechanichal relay
Real Time Clock
Permissible ambient conditions:
Ambient temperature
for controller operation
for transport/storage
Air humidity
for controller operation
for transport/storage
Other specifications and dimensions
Housing design
Installation methods
Overall dimensions
Cut out installation dimensions
Display
Light diode
Operation
B.2.

Resistance table for PT1000 sensors

0 10
°C
Ω 1000 1039
* note:
3 ~: You can also switch 3 ~ pumps with the control. Please use one of the additional switch boxes for this
according to the current intensity 2716600920..923. (Engine protection and contactor and comfortable clam-
ping of the accessories and a 2 meter multi-pole cable are contained in the switch box).
1 ~: You can also switch 1 ~ pumps of higher current intensity with the control. Use the additional switch
boxes 2716600924. (A contactor and comfortable clamping of the accessories and a 2 meter multi-pole cable
are contained in the switch box).

Description of controller

230 VAC +/-10 %
50 - 60 Hz
1.5 W - 2.3 W
4 A slow blow 250 V
IP40/IP 44 (only with the supplied gasket set)
II
II
II
2 (R2-R3)
3
< 30 m
< 10 m
< 3 m
< 10 m
RTC with 24 hour power reserve
0 °C - 40 °C
0 °C - 60 °C
max. 85 % rel. humidity at 25 °C
no moisture condensation permitted
2 part, ABS plastic
Wall installation, optional panel
163 mm x 110 mm x 52 mm
157 mm x 106 mm x 31 mm
Fully graphical display, 128 x 64 dots
Multicolor red/green
4 entry keys
20 30 40
1077
1116 1155
* Note for 3 ~ and 1 ~ pumps, see
below
50 60 70
1270
1194 1232
80 90 100
1308
1347 1385
