5.1.8.1. Signal at ∆T + 0 K
This signal appears if the ΔT value between the reference sensors reaches 0 K.
Setting range: 0 % - 100 %/Default: 1 %
5.1.8.2. Signal at ∆T + 20 K
The signal level rises up to the value set if the ΔT value between the reference
sensors reaches 20 K.
Setting range: 0 % - 100 %/Default: 99 %
5.1.8.3. Signal at ∆T > 20 K
If the ΔT value between the reference sensors exceeds 20 K, the signal set
here will appear.
Setting range: 0 % - 100 %/Default: 100 %

5.2. Auxiliary heating

Auxiliary heating
When selecting systems with auxiliary heating, this menu, in which the neces-
sary settings can be made, is displayed.

5.2.1. Tset S2

Target temperature for sensor 2. Below this temperature the heating is switched
on until Tset S2+Hysteresis is reached.
Setting range: 0 °C - 40 °C/Default: 20 °C

5.2.2. Hysteresis

Hysteresis for heating.
Setting range: 0 °C - 10 °C/Default: 5 °C

5.3.3. Heating times

During the periods set here the heating system is enabled.
Setting range: off, daily 0:00 - 23:59/Default: daily 0:00 - 23:59
Settings
21
