7. Special functions

7.1. Program selection

The suitable hydraulic variant for the specific application is selected and set here (see
"B.6. Hydraulic variants" on page 7). The associated diagram is displayed after
pressing "Info".
Setting range: 1 - 4/Default: 1
Normally the program selection is made only once during initial commis-
sioning by the specialist. Incorrect program selection can lead to unpre-
dictable errors.
Caution

7.2. Time and date

This menu is used to set the current time and date.
For analysis of the system data it is essential that the time is set accu-
rately on the controller. Please note that the clock has a 24 hour battery
reserve if the mains voltage is interrupted and must therefore be reset
Caution
afterwards.

7.3. Sensor calibration

Deviations in the temperature values displayed, for example due to cables which are
too long or sensors which are not positioned optimally, can be compensated for manu-
ally here. The settings can be made for each individual sensor in steps of 0.5 °C.
Offset S1 - S3 per setting range: -100 - +100 (translates to -50 °C - +50 °C)
Default: 0 °C
Settings are only necessary in special cases at the time of initial com-
missioning by the specialist. Incorrect measurement values can lead to
unpredictable errors.
Caution
26
Special functions
The menu "7. Special functions" is used to set
basic items and expand functions.
Caution
The menu is closed by pressing the "esc" key
or selecting "Exit special functions".
Other than the time, all settings
may only be made by a special-
ist.
