5.12 Changing modulating control setting
MODULATING CONTROL
select
Modulating control can be set at on/off. The device modulates based on pulse-pause modulation
from 1K below setpoint.
5.13 Switching overtime timer on/off
It is possible with this function to switch 1, 2 or 3 hours manually to the day-time temperature
outside the set switching times.
The yellow LED with the symbol
will also be indicated on the display immediately beneath the remaining time in minutes before the
function switches off again and the PinTherm Infra II operates again at the night-time temperature.
In the meantime, the function can also be switched off again by pressing the button until the
yellow LED goes out and the number of minutes is no longer indicated on the display. See image
below.
MON
MON
5.14 Replacing PinTherm Infra II factory settings
If you use this function, all the factory settings will be re-set again. This function can be performed
at any time. See image below.
RESET TO DEFAULT
SETTINGS?
OK
keep pressed or
+/- 12 secs
6.0 Discarding PinTherm Infra II
Whenever the PinTherm Infra II is replaced or removed, it should be recycled or scrapped in
accordance with national regulations and/or local by-laws.
will light up indicating that the function is switched on. It
17:01 18°C
NIGHT
17:01 18°C
DAY X:120
This will return you to the
ESC
screen from which you
selected this function and
default settings will not be
restored.
MODULATING CONTROL
OFF
OK
select
on or off
MON 17:01 18°C
DAY X:060
MON 17:01 18°C
DAY X:180
DEFAULT SETTINGS
RESTORED!
OK
SELECT LANGUAGE
ENGLISH
MON 08:01
DAY
OK
back to the
menu
16°C
13
